Sensor solutions for installation in the winding head
Recording the temperature at the winding head is crucial for the operational safety of ever larger and more powerful systems. Excessive heating can destroy the insulation, resulting in serious damage. The maximum winding temperature, specified by the thermal resistance of the insulating materials, must not be exceeded. Our specially assembled sensors offer the best possible protection and ensure that insulating sleeves, insulating resins and slot insulation are not damaged.
Advantages at a glance
- Measurement and monitoring of the winding temperature during active operation: Protects against overheating and increases the service life of the systems.
- Prevention of EMC and ESD interference: Operational safety is increased by suitable sensor insulation.
- Protection of insulation materials: Prevents damage to insulation materials and maintains the functionality of the system.
- Reduction of downtimes and production losses: Reliable protection of windings leads to less unplanned downtime.
Cable sensor from Alpha Therm
Our cable sensors are versatile and offer solutions for a wide range of temperature measurement tasks.
Product features:
- Operating temperature range: -70°C to +260°C
- Universal application possibilities: Suitable for various temperature measurements.
- High-voltage-resistant insulation: Provides safety in demanding environments.
- Special version with protection class IP 66: For particularly challenging operating conditions.
- Optional: PFAS-free versions
Description: Cable sensors with heat-shrink tubing insulation are ideal for temperature measurements of all kinds and are mainly used as winding head sensors for thermal motor protection. Depending on the application and temperature requirements, our sensors are insulated once or twice with shrink tubing made of Kynar, Kynarflex, FEP or PTFE. The connection cables are available in PFA single strands, Teflon hose lines or Teflon flat ribbon hose lines and can be configured in 2 / 3 or 4-wire circuits. The cable cross-section ranges from AWG20 to AWG30 and the cable length is freely selectable. Waterproof versions with protection class IP 66 and high-voltage versions up to 8 kV (special versions even up to 20 kV) are possible.
Quality from Germany
Our sensors are manufactured by Alpha Therm in Germany, which ensures the highest quality standards and reliability. Rely on our expertise and ensure optimum protection for your systems.
